Canon C700
The Canon EOS C700 is a high-end cinema camera available in Super 35mm (4.5K) and full-frame (5.9K) sensor versions. It offers over 15 stops of dynamic range and supports internal recording in XF-AVC and ProRes formats, with RAW capture available via an optional Codex recorder.
With a modular design, multiple mounting points, and support for EF and PL lens mounts, the C700 is built for flexibility. It features Canon’s Dual Pixel CMOS AF, supports high frame rates, Canon Log 2/3, and is compatible with ACES and HDR standards, making it ideal for top-tier film and TV production.
Model
Canon C700 Full-Frame
Sensor
5.9K Full-Frame CMOS Sensor with DAF
Lens Mount
PL / EF
Recording Format
XF-AVC 10-bit 4:2:2 YCC
XF-AVC 10/12-bit 4:4:4:4 RGB
XF-AVC 8-bit 4:2:0 YCC (proxy)
ProRes 10-bit 4:2:2 YCC
ProRes 12-bit 4:4:4:4 RGB
File Format
| XF-AVC | MXF |
| ProRes | MOV |
| Raw | RMF |
*RAW via a Codex Drive or SDI. SDI limited to 50P at 4096×2160 10-bit
Internal Recording Resolution
| 4K | 4096×2160 |
| UHD | 3840×2160 |
| 2K | 2048×1080 |
| HD | 1920×1080 |
*Approx. 18.69 megapixels (5952 x 3140): When 4096 x 2160 or 2048 x 1080 is selected as the resolution
* Approx. 17.52 megapixels (5580 x 3140): When 3840 x 2160 or 1920 x 1080 is selected as the resolution
External Recording Resolution
| 6K | 5952×3140 |
| 4K | 4096×2160 |
| 2K | 2048×1080 |
Maximum Frame Rate (PAL)
| 4K XF-AVC YCC 4:2:2 10-bit | 50 fps |
| 4K ProRes YCC 4:2:2 10-bit | 25 fps |
| UHD XF-AVC YCC 4:2:2 10-bit | 50 fps |
| UHD ProRes YCC 4:2:2 10-bit | 50 fps |
| 2K XF-AVC RGB 4:4:4:4 12-bit | 50 fps |
| 2K XF-AVC RGB 4:4:4:4 10-bit | 50 fps |
| 2K XF-AVC YCC 4:2:2 10-bit | 100 fps |
| 2K XF-AVC YCC 4:2:2 10-bit (sensor crop) | 200 fps |
| 2K XF-AVC YCC 4:2:0 8-bit (proxy) | 25 fps |
| 2K ProRes RGB 4:4:4:4 10-bit | 50 fps |
| 2K ProRos YCC 4:2:2 10-bit | 50 fps |
Media
| Internal Recording | CFast 2.0 |
| Proxy Recording | SD |
| Setup | SD |
Audio Recording Format
LPCM 2CH 24-bit 48-kHz
ISO
| ISO Range | 100-102,400 |
Internal ND Filters
Clear
IRND 0.6 (2 Stops)
IRND 1.2 (4 Stops)
IRND 1.8 (6 Stops)
IRND 2.4 (8 Stops with Extended ND)
IRND 3.0 (10 Stops with Extended ND)
Batteries
V-Lock
Inputs
1x BNC (Genlock)
1x BNC (Timecode I/O)
1x Ethernet (I/O)
1x 2.5mm Terminal (Remote Control)
2x XLR 3-pin (Audio)
1x 3.5mm Mini-Jack (Audio)
1x XLR 4-pin (Power)
Outputs
2x BNC (Monitor)
4x BNC (SDI)
1x HDMI
1x 3.5mm Mini-Jack (Headphones)
1x D-Tap
1x Lemo 2-pin (DC 12V Power)
1x Lemo 3-pin (DC 24V Power)
Weight
3.4 kgs
